| WEIGHT LIMIT | 100kg |
| FRAME MATERIAL | ALLOY |
| FRAME DESCRIPTION | STEP THROUGH ALLOY 6061 REMOVABLE BATTERY |
| FRAME STYLE | STEP-THROUGH |
| FORK MATERIAL | STEEL |
| FORK BRAND | PEDAL |
| FORK DESCRIPTION | STEEL BLADED |
| FRONT TRAVEL | |
| DERAILLEUR FRONT | 1X |
| DERAILLEUR REAR | SHIMANO TOURNEY 7 SPEED |
| GROUPSET | SHIMANO MIXED |
| SHIFTERS | SHIMANO REVO 7 SPEED |
| BRAKES | TEKTRO HD-M275 |
| BRAKE TYPE | HYDRAULIC DISC BRAKE |
| ROTOR FRONT | 180MM 6 BOLT |
| ROTOR REAR | 180MM 6 BOLT |
| CRANKSET AND FRONT CHAINRINGS | 46T- ED STEEL, W/DOUBLE RESIN CG 170MM ALLOY ARM |
| BOTTOM BRACKET | SEALED BSA CARTRIDGE 68X122.5MM |
| CHAIN | KMC 7 SPEED |
| PEDALS | 9/16 RESIN PLATFORM |
| REAR GEARS | 7 SPEED |
| CASSETTE DESCRIPTION | SHIMANO TZ500 14-28T |
| HANDLEBAR | ALLOY W:620MM, R:20MM, BACKSWEEP:22D, Ř:25.4MM |
| HANDLEBAR STEM | QUILL 90MM*35D Ř:25.4MM BLACK |
| HEADSET | THREADED (H112N) 44/30 23mm |
| GRIPS / BAR TAPE | XL-G78 BLACK ERGO RUBBER (FOR TWIST SHIFT) |
| SEAT POST | 27.2MM*300 MM ALLOY SINGLE BOLT |
| SADDLE | BKS-1057 265x180MM BLACK COMFORT (ENVIRO-FRIENDLY) |
| FRONT AND REAR HUBS | F: SF-A201F NUTTED |
| FRONT AND REAR RIMS | HLQC-04B, H:29-30MM,27.5x 13G x 36H?BLACK CNC A/V |
| FRONT AND REAR TYRES | KENDA K1153 27.5x2.1" XC MULTI USE TREAD |
| SPOKE | F: 13G 283MM, R: 13G 245/247 (1:4) |
| WHEEL SIZE | 27.5" (650b) |
| FRONT AND REAR LIGHTS | |
| FENDER | 50MM PVC TYPE (SUIT UP TO 700C) |
| ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER) | REAR KICKSTAND, 42V 2A CHARGER (3 PIN FOR 36V BATTERY) |
| DRIVE UNIT LOCATION | REAR WHEEL |
| DRIVE UNIT DESCRIPTION | CZJB 110 PLANETARY DRIVE |
| MOTOR POWER (WATTS) | 250 |
| MOTOR TORQUE (NM) | 40 |
| BATTERY DESCRIPTION | REMOVABLE REAR RACK STYLE W/INTERNAL BMS |
| BATTERY SIZE (WATT-HOURS) | 280 |
| CHARGE TIME (HOURS) | 5 |
| DISPLAY | KD-58C |
| ASSIST MODES | 5 MODES |
| RANGE (KMS) | 30 |
| IP RATING | IP54 |
