| WEIGHT LIMIT | 100kg |
| FRAME MATERIAL | ALLOY |
| FRAME DESCRIPTION | STEP OVER FOLDING ALLOY 6061 REMOVABLE BATTERY |
| FRAME STYLE | STEP-OVER |
| FORK MATERIAL | STEEL |
| FORK BRAND | PEDAL |
| FORK DESCRIPTION | STEEL BLADED |
| FRONT TRAVEL | |
| DERAILLEUR FRONT | 1X |
| DERAILLEUR REAR | SHIMANO TOURNEY 7 SPEED |
| GROUPSET | SHIMANO MIXED |
| SHIFTERS | LTWOO TRIGGER 7 SPEED |
| BRAKES | ALLOY V V BRAKE 110mm |
| BRAKE TYPE | V BRAKE |
| ROTOR FRONT | RIM |
| ROTOR REAR | RIM |
| CRANKSET AND FRONT CHAINRINGS | 48T- ED STEEL, W/DOUBLE RESIN CG 170MM ALLOY ARM |
| BOTTOM BRACKET | SEALED BSA CARTRIDGE 68X119L |
| CHAIN | LIXING 7 SPEED |
| PEDALS | 9/16 FOLDING RESIN |
| REAR GEARS | 7 SPEED |
| CASSETTE DESCRIPTION | SHIMANO TZ500 14-28T |
| HANDLEBAR | ALLOY W:600MM, R:30MM, BACKSWEEP:6D FOR FOLDING STEM |
| HANDLEBAR STEM | RIGHT ANGLE FOLDING STEM, TELESCOPIC, 9D FORWARD TILT w/SAFETY LINE MARKED |
| HEADSET | 1-1/8" 44x30MM H:11.7MM SEMI-INTEGRATED |
| GRIPS / BAR TAPE | XL-G78 BLACK ERGO RUBBER 135mm |
| SEAT POST | 33.9MM*500MM (200MM MINIMUM INSERTION) |
| SADDLE | BKS-1071 BLACK COMFORT (ENVIRO-FRIENDLY) |
| FRONT AND REAR HUBS | F: SF-A201F,13G*36H NUTTED |
| FRONT AND REAR RIMS | YK-20 DOUBLE WALL 20" *1.5 " *13G*36H W/CNC EDGE |
| FRONT AND REAR TYRES | J-154 20X2.1" BLACK WIRE BEAD |
| SPOKE | F: 13G 180MM (4 CROSS), R: 13G 135/137MM (2 CROSS) |
| WHEEL SIZE | 20" |
| FRONT AND REAR LIGHTS | |
| FENDER | 50MM PVC TYPE |
| ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER) | CENTRE KICKSTAND, 42V 2A CHARGER (3 PIN FOR 36V BATTERY) |
| DRIVE UNIT LOCATION | REAR WHEEL |
| DRIVE UNIT DESCRIPTION | PLANETARY DRIVE BRUSHLESS TYPE (SHENGYI / CZJB) |
| MOTOR POWER (WATTS) | 250 |
| MOTOR TORQUE (NM) | 32 |
| BATTERY DESCRIPTION | REMOVABLE REAR RACK STYLE W/INTERNAL BMS |
| BATTERY SIZE (WATT-HOURS) | 280 |
| CHARGE TIME (HOURS) | 5 |
| DISPLAY | KD-58C |
| ASSIST MODES | 5 MODES |
| RANGE (KMS) | 30 |
| IP RATING | IP54 |
