| FRAME MATERIAL | ALLOY |
| FRAME DESCRIPTION | STEP OVER ALLOY 6061 REMOVABLE BATTERY |
| FRAME STYLE | STEP-OVER |
| FORK MATERIAL | STEEL |
| FORK BRAND | SR SUNTOUR |
| FORK DESCRIPTION | COIL CAST ALLOY XCM30 W/LOCKOUT |
| FRONT TRAVEL | 100MM |
| DERAILLEUR FRONT | 1X |
| DERAILLEUR REAR | SHIMANO 8 SPEED |
| GROUPSET | SHIMANO MIXED |
| SHIFTERS | 8 SPEED TRIGGER |
| BRAKES | TEKTRO HD-M275 |
| BRAKE TYPE | HYDRAULIC DISC BRAKE |
| ROTOR FRONT | 180MM 6 BOLT |
| ROTOR REAR | 160MM 6 BOLT |
| CRANKSET AND FRONT CHAINRINGS | 38T- ED STEEL, W/ALLOY BLK CG, 170MM ALLOY ARM |
| BOTTOM BRACKET | INTEGRATED |
| CHAIN | KMC 8 SPEED |
| PEDALS | 9/16 RESIN PLATFORM |
| REAR GEARS | 8 SPEED |
| CASSETTE DESCRIPTION | SHIMANO HG200 12-32T |
| HANDLEBAR | MTB RISER BAR STYLE, W: 680MM, R: 20MM, BACKSWEEP: 9D, BARBORE: 31.8MM |
| HANDLEBAR STEM | A HEAD, EXT: 70MM, H: 41MM, BAR BORE: 31.8MM, ED BOLT |
| HEADSET | A HEAD,28.6MM,44*44MM,W/15MM RESIN BLACK CONE |
| GRIPS / BAR TAPE | JT-G106 TEXTURED RUBBER L/R:125MM, CLOSED END |
| SEAT POST | 30.9*350MM, W/ALLOY HEAD |
| SADDLE | MTB STYLE SW-6670 BLACK COVER, ED RAIL |
| FRONT AND REAR HUBS | F: SF-A262F, M9,36H*13G, R: Hub Motor |
| FRONT AND REAR RIMS | RD-H20 27.5"*36H*14G, DOUBLE WALL, A/V W/EYELETS |
| FRONT AND REAR TYRES | W3102 MTB KNOBBLY STYLE - 29" x 2.25" |
| WHEEL SIZE | 29" (700c) |
| FRONT AND REAR LIGHTS | NA |
| FENDER | NA |
| ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER) | KICKSTAND, 42V 2A CHARGER (3 PIN FOR 36V BATTERY) |
| DRIVE UNIT LOCATION | REAR WHEEL |
| DRIVE UNIT DESCRIPTION | CZJB 90T2 PLANETARY DRIVE |
| MOTOR POWER (WATTS) | 250 |
| MOTOR TORQUE (NM) | 40 |
| BATTERY DESCRIPTION | REMOVABLE 36V EEL MINI |
| BATTERY SIZE (WATT-HOURS) | 417 |
| CHARGE TIME (HOURS) | 5 |
| DISPLAY | KD-58C |
| ASSIST MODES | 5 MODES |
| RANGE (KMS) | 50 |
| IP RATING | IP54 |
| WEIGHT LIMIT | 100KG |
