| WEIGHT LIMIT | 102KG |
| FRAME MATERIAL | ALLOY |
| FRAME DESCRIPTION | STEP-THROUGH ALLOY 6061 REMOVABLE BATTERY |
| FRAME STYLE | STEP-THROUGHT |
| FORK MATERIAL | STEEL |
| FORK BRAND | SR SUNTOUR |
| FORK DESCRIPTION | COIL CAST ALLOY XCM32 W/LOCKOUT |
| FRONT TRAVEL | 100MM |
| DERAILLEUR FRONT | 1X |
| DERAILLEUR REAR | SHIMANO 9 SPEED |
| GROUPSET | SHIMANO MIXED |
| SHIFTERS | 9 SPEED TRIGGER |
| BRAKES | TEKTRO HD-M275 |
| BRAKE TYPE | HYDRAULIC DISC BRAKE |
| ROTOR FRONT | 180MM 6 BOLT |
| ROTOR REAR | 160MM 6 BOLT |
| CRANKSET AND FRONT CHAINRINGS | 38T- NW - STEEL, W/SINGLE ALLOY CG 170MM ALLOY ARM |
| BOTTOM BRACKET | INTEGRATED |
| CHAIN | KMC 9 SPEED |
| PEDALS | 9/16 RESIN PLATFORM |
| REAR GEARS | 9 SPEED |
| CASSETTE DESCRIPTION | SHIMANO HG 11-36T |
| HANDLEBAR | MTB RISER BAR STYLE, W: 680MM, R: 28MM, BACKSWEEP: 30D, BARBORE: 31.8MM |
| HANDLEBAR STEM | A HEAD STEM, EXT: 60MM, H: 41MM, BAR BORE: 31.8MM, ED BOLT |
| HEADSET | A HEAD,28.6MM,44*44MM,W/15MM RESIN BLACK CONE |
| GRIPS / BAR TAPE | ERGO HL-G315 L/R:136.5MM, CLOSED END,ALLOY LOCK |
| SEAT POST | 30.9*350MM, W/ALLOY HEAD |
| SADDLE | SELLE ROYAL MTB SPORT 4007HRN |
| FRONT AND REAR HUBS | F: SF-A262F 36H QR 6 BOLT LBB / R: SF-A626R 36H QR 6 BOLT 10MM 135MM LBB |
| FRONT AND REAR RIMS | RD-H20 27.5"*32H*14G, DOUBLE WALL, A/V W/EYELETS |
| FRONT AND REAR TYRES | MAXXIS REKON M349 - 27.5" x 2.4" |
| SPOKE | |
| WHEEL SIZE | 27.5" (650B) |
| FRONT AND REAR LIGHTS | NA |
| FENDER | NA |
| ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER) | KICKSTAND, 42V 2A CHARGER (3 PIN FOR 36V BATTERY) |
| DRIVE UNIT LOCATION | MID DRIVE |
| DRIVE UNIT DESCRIPTION | ANANDA M81 CANBUS |
| MOTOR POWER (WATTS) | 250 |
| MOTOR TORQUE (NM) | 80 |
| BATTERY DESCRIPTION | REMOVABLE 36V RHINO TOP LOAD |
| BATTERY SIZE (WATT-HOURS) | 468 |
| CHARGE TIME (HOURS) | 6 |
| DISPLAY | D18 COLOUR BLUETOOTH (CANBUS) |
| ASSIST MODES | 5 MODES |
| RANGE (KMS) | 70 |
| IP RATING | IP54 |
