| FRAME | 6061 Aluminum Frame, 130mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| FORK | Rock Shox Recon RL, 140mm, 44mm offset |
| REAR SHOCK | X-Fusion 02 Pro R AV, 210x50mm standard |
| HEADSET | Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 ) |
| HEADSET SPACER | 1 x 10mm |
| GRIPS | Propalm Pro, 130mm length |
| HANDLE BAR | Norco 6061 DB Alloy, 800mm, 25mm rise |
| STEM | Norco 6061 Alloy 40mm length, 35mm clamp |
| SEAT POST | TranzX YSI34 Dropper, 34.9mm, 150mm (S) - 170mm (M) - 200mm (L, XL, XXL) |
| SEAT POST CLAMP | Norco Alloy Nutted Clamp, 38.5 ID |
| SADDLE | Norco Trail |
| FRONT BRAKE | Tektro HD-M535, 4 Piston, Resin pads |
| FRONT BRAKE ROTOR | TRP TR180, 180mm, 2.3mm Thickness, 6 bolt |
| REAR BRAKE | Tektro HD-M535, 4 Piston, Resin pads |
| REAR BRAKE ROTOR | TRP TR180, 180mm, 2.3mm Thickness, 6 bolt |
| BRAKE LEVERS | Tektro HD-M535 |
| SHIFTER REAR | Shimano CUES SL-U6000, 10sp |
| REAR DERAILLEUR | Shimano CUES SL-U6000, 10sp |
| CASSETTE | Shimano CUES LG-400, 11-48T, 10sp |
| CHAIN | Shimano LG-500, 10sp |
| CRANKSET | Shimano Cues FC-U6000, 30T, CL52, 170mm (S), 175mm (M-XXL) |
| BOTTOM BRACKET | Shimano BB-MT501, 73mm BSA |
| FRONT HUB | Formula DC-511, 15x110, 32H, 6 bolt |
| FRONT HUB SKEWER | Rock Shox Maxle Stealth 15x110mm |
| REAR HUB | Formula DC-3248, 12x148, HG, 32H, 6 bolt |
| REAR HUB SKEWER | 148mm x 12mm TA, TL13 M12x1.0 |
| SPOKES/NIPPLES | Stainless Steel, 14g |
| RIMS | WTB ST, 32H, F/R-29", 30mm ID |
| FRONT TIRE | Continental Kryptotal-F, Trail, Endurance, 29" x 2.4", Foldable |
| REAR TIRE | Continental Xynotal, Trail, Endurance,29" x 2.4", Foldable |
