FRAME | SCULTURA CF3 V; MAT carbon; 700x30C max. WHS; 100x12/ 142x12 AST; Pressfit 86,5 |
FORK | SCULTURA CF3 disc; MAT carbon; 700x30C max. WHS |
BRAKE LEVER | Shimano 105 |
BRAKE - FRONT | Shimano 105; Hydraulic disc |
BRAKE - REAR | Shimano 105; Hydraulic disc |
ROTOR - FRONT | Shimano RT64; 160mm |
ROTOR - REAR | Shimano RT64; 160mm |
C-HOUSING | |
CHAIN | Shimano CN-M6100-12 |
CHAINWHEEL | Shimano 105; FCR7100, 52-36 ATC |
CRANK/SIZE | 165 mm-3S/XXS, 170 mm-XS, 172.5 mm-S/M/L, 175 mm-XL |
BB SET | SM-BB71-41B, Pressfit 86.5 |
DERAILLEUR - FRONT | Shimano 105 Di2 |
DERAILLEUR - REAR | Shimano 105 Di2 |
FREEWHEEL | Shimano CS-R7101; 11-34 ATC; 12 GER |
PEDAL | |
GRIP | MERIDA ROAD Expert |
HANDLEBAR | MERIDA EXPERT SLII; MAT aluminium; 380mm(3S-XXS-XS-S) , 400mm (M-L-XL) |
H-B STEM | EXPERT SL 2PII; MAT aluminium; -9 ASD |
H-STEM/SIZE | 90mm-3S/XXS/XS, 100 mm-S, 110 mm-M/L, 120 mm-XL |
HUB - FRONT | |
HUB - REAR | |
AXLE - FRONT | MERIDA EXPERT TR |
AXLE - REAR | MERIDA EXPERT SL; including removable lever; 6/4mm allen key |
RIM | VISION SC30 DB; 100x12 WHF; 142x12 WHR; 19 IWR; 33 HRI; Centerlock; MAT carbon |
SADDLE | MERIDA EXPERT SL; 6% recycled and 23% nature material; V-mount; incl. MERIDA minitool |
SEAT CLAMP | MERIDA EXPERT |
SEAT POST | MERIDA EXPERT CC; 27.2 DSP; 15 SSB; Carbon |
SHIFTER - FRONT | Shimano 105 disc Di2 |
SHIFTER - REAR | Shimano 105 disc Di2 |
TYRE - FRONT | Maxxis Highroad; 700x28C; fold;tubeless ready |
TYRE - REAR | Maxxis Highroad; 700x28C; fold;tubeless ready |
E-SHIFT PARTS-2 | Battery BT-DN300 |
E-SHIFT PARTS-3 | Shimano SW-ED300 x 2 |
OTHER 5 | MERIDA Multitool with saddlebox |
