| FRAME | ONE-TWENTY LITE V; 130 STR; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| SHOCK | Marzocchi Bomber inline; lockout |
| FORK | Marzocchi Bomber Z2; Air; 130 STR; Tapered; 44mm fork offset; platform; 29x2.6" max WHS |
| BRAKE - FRONT | Shimano Deore M6120; 4 piston |
| BRAKE - REAR | Shimano Deore M6100; 2 piston |
| ROTOR - FRONT | Shimano RT30; 203mm |
| ROTOR - REAR | Shimano RT30; 180mm |
| CHAIN | KMC X12 |
| CHAINGUARD | |
| CHAINWHEEL | Shimano Deore MT512; 32 ATC |
| CRANK/SIZE | 170 mm for all sizes |
| BB SET | Shimano BB-MT-501; 24mm |
| DERAILLEUR - FRONT | |
| DERAILLEUR - REAR | Shimano Deore M6100; SGS |
| FREEWHEEL | Shimano Deore M6100; 10-51 ATC; 12 GER |
| PEDAL | |
| GRIP | MERIDA COMP EC |
| H-BAR | MERIDA EXPERT TR II; MAT aluminium; 780 WHB; 18 RHB |
| H-B STEM | MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
| H-STEM/SIZE | 40 mm |
| HUB - FRONT | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB - REAR | Shimano TC500-MS-B; 148x12 WHR; 32 SPH; Centerlock |
| AXLE - REAR | MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
| RIM | MERIDA COMP TR; 29 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included) |
| SADDLE | MERIDA COMP SL; 25% recycled material; V-mount; incl. MERIDA minitool |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XSHORT/SHORT: 150 SPT - MID: 170 SPT - LONG, XLONG: 200 SPT |
| SHIFTER - FRONT | Shimano SL-MT500-IL |
| SHIFTER - REAR | Shimano Deore M6100 |
| TYRE - FRONT | Maxxis Dissector; 29x2.4"; fold; TR EXO 3C MaxxTerra |
| TYRE - REAR | Maxxis Forekaster; 29x2.4"; fold; TR Dual |
| BOTTLE CAGE | |
| E-SHIFT PARTS-1 | |
| OTHER 1 | |
| OTHER 2 | Velcro strap & Tube Base Mount LITE |
| OTHER 3 | |
| OTHER 4 | |
| OTHER 5 |
| Frame Name | ONE-TWENTY LITE V | ONE-TWENTY LITE V | ONE-TWENTY LITE V | ONE-TWENTY LITE V | ONE-TWENTY LITE V |
| Frame Size Name | XShort | Short | Mid | Long | XLong |
| Tyre Sizes | 29" | 29" | 29" | 29" | 29" |
| Frame Size Inch | |||||
| ST seat tube [mm] | 400 | 410 | 425 | 445 | 470 |
| Ste Seat Tubes Effective Mm | |||||
| STA seat tube actual [mm] | |||||
| TT top tube [mm] | 548 | 569 | 590 | 611 | 632 |
| CS chain stay length [mm] | 435 | 435 | 435 | 435 | 435 |
| HTA head tube angle [°] | 66 | 66 | 66 | 66 | 66 |
| STA seat tube angle [°] | 78.5 | 78.5 | 78.5 | 78.5 | 78.5 |
| Stae Seat Tube Angle Effective Deg | |||||
| Staa Seat Tube Angle Actual Deg | |||||
| BD bottom bracket drop [mm] | 40 | 40 | 40 | 40 | 40 |
| HT head tube [mm] | 95 | 100 | 105 | 110 | 115 |
| FL fork length [mm] | 541 | 541 | 541 | 541 | 541 |
| FO fork offset [mm] | |||||
| R reach [mm] | 425 | 445 | 465 | 485 | 505 |
| S stack [mm] | 604 | 609 | 613 | 618 | 622 |
| WB wheel base [mm] | 1155 | 1177 | 1199 | 1221 | 1243 |
| SH stand over height [mm] | 748 | 750 | 752 | 754 | 756 |
