| FRAME | eSPRESSO CITY LITE II; MAT aluminium; 700x50C (with fender) max. WHS; 135x9 AST; internal |
| SHOCK | |
| FORK | SR Suntour NEX E25; Coil; 63 STR; 700x52C max WHS |
| BRAKE - FRONT | Shimano MT-200; 2 piston |
| BRAKE - REAR | Shimano MT-200; 2 piston |
| ROTOR - FRONT | Shimano RT10; 180 mm |
| ROTOR - REAR | Shimano RTEM300; 180 mm |
| CHAIN | Shimano LG500 |
| CHAINWHEEL | SM-CRE50 38T W/O CG |
| CRANK/SIZE | Shimano FC-E5010; 165mm |
| BB SET | |
| DERA - FRONT | |
| DERA - REAR | Shimano CUES U4000 |
| FREEWHEEL | Shimano LG300; 11-41 ATC; 9 GER |
| PEDAL | VP VPE-891 |
| GRIP | MERIDA EXPERT TK |
| H-BAR | MERIDA EXPERT; MAT aluminium; 640 WHB; 35 RHB |
| H-B STEM | MERIDA EXPERT; MAT aluminium; 31.8 DSH; adjustable |
| STEM/SIZE | 65 mm-XS/S/M, 90 mm-L/XL |
| HEAD SET | MERIDA 8252 |
| HUB - FRONT | Shimano QC300; 100x9 WHF; 32 SPH; Centerlock |
| HUB - REAR | Shimano QC300; 135x9 WHR; 36 SPH; Centerlock |
| AXLE - FRONT | |
| AXLE - REAR | |
| RIM | MERIDA COMP TK; 20 IWR; MAT aluminium |
| RIM TAPE | |
| SADDLE | MERIDA EXPERT CT; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | JD-SP79; 30.9 DSP; 15 SSB; 40 SST |
| SHIFTER - FRONT | |
| SHIFTER - REAR | Shimano CUES U4000 |
| INNER TUBE | 700*32/50 |
| TYRE - FRONT | Continental Ride Cruiser |
| TYRE - REAR | Continental Ride Cruiser |
| BOTTLE CAGE | BOTTLE CAGE ADAPTER, BK-003 |
| CARRIER | MERIDA MIK HD Carrier with Spring clip |
| FENDER | Sunnywheel SW-FA311-60E1 (MSB) |
| KICKSTAND | Atranvelo ED-100-PC |
| LIGHT - FRONT | Herrmans H-Black MR4 E |
| LIGHT - REAR | Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier |
| FRAME LOCK | Abus 4650 XL |
| DRIVE UNIT | Shimano E5000; 40Nm |
| DRIVE COVER | CR-028 + SM-DUE50 |
| BATTERY | Shimano EN805-L 504Wh |
| BATTERY CHARGER | Shimano EC-E6002; 2A charging current |
| BATTERY LOCK | Abus Key |
| DISPLAY | Shimano SC-E5000 |
| Frame Name | eSPRESSO CITY LITE II | eSPRESSO CITY LITE II | eSPRESSO CITY LITE II | eSPRESSO CITY LITE II | eSPRESSO CITY LITE II |
| Frame Size Name | XS | S | M | L | XL |
| Tyre Sizes | 28" | 28" | 28" | 28" | 28" |
| Frame Size Inch | |||||
| ST seat tube [mm] | 380 | 430 | 480 | 530 | 580 |
| Ste Seat Tubes Effective Mm | |||||
| STA seat tube actual [mm] | |||||
| TT top tube [mm] | 580 | 595 | 615 | 635 | 655 |
| CS chain stay length [mm] | 470 | 470 | 470 | 470 | 470 |
| HTA head tube angle [°] | 70 | 70 | 70 | 70 | 70 |
| STA seat tube angle [°] | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Stae Seat Tube Angle Effective Deg | |||||
| Staa Seat Tube Angle Actual Deg | |||||
| BD bottom bracket drop [mm] | 65 | 65 | 65 | 65 | 65 |
| HT head tube [mm] | 170 | 175 | 180 | 190 | 200 |
| FL fork length [mm] | 475 | 475 | 475 | 475 | 475 |
| FO fork offset [mm] | |||||
| R reach [mm] | 386 | 399 | 418 | 435 | 452 |
| S stack [mm] | 656 | 661 | 665 | 675 | 684 |
| WB wheel base [mm] | 1113 | 1128 | 1149 | 1169 | 1190 |
| SH stand over height [mm] | 413 | 413 | 412 | 412 | 411 |
