FRAME |
eSPRESSO CC LITE III; MAT aluminium; 27,5x2,25" max. WHS; 135x9 AST; internal |
SHOCK |
|
FORK |
Suntour NVX30 DS; Coil; 80 STR; 27,5x2,4" max WHS |
BRAKE - FRONT |
Shimano MT-200; 2 piston |
BRAKE - REAR |
Shimano MT-200; 2 piston |
ROTOR - FRONT |
Shimano RT10; 180 mm |
ROTOR - REAR |
Shimano RTEM300M; 180 mm |
CHAIN |
Shimano LG500 |
CHAINWHEEL |
Samox NWP203 ; 38 ATC |
CRANK/SIZE |
MERIDA EXPERT TK; 165mm |
BB SET |
|
DERA - FRONT |
|
DERA - REAR |
Shimano CUES U6000; GS |
FREEWHEEL |
Shimano LG300; 11-48 ATC; 10 GER |
PEDAL |
VP VPE-891 |
GRIP |
MERIDA EXPERT TK |
H-BAR |
MERIDA EXPERT; MAT aluminium; 660 WHB; 15 RHB |
H-B STEM |
MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable |
STEM/SIZE |
90 mm- XS/S/M/L/XL |
HEAD SET |
MERIDA-8254 |
HUB - FRONT |
Shimano QC300; 100x9 WHF; 32 SPH; Centerlock |
HUB - REAR |
Shimano QC300; 135x9 WHR; 32 SPH; Centerlock |
AXLE - FRONT |
|
AXLE - REAR |
|
RIM |
MERIDA COMP TK; 20 IWR; MAT aluminium |
RIM TAPE |
|
SADDLE |
MERIDA EXPERT TK II; V-mount |
SEAT CLAMP |
MERIDA EXPERT |
SEAT POST |
JD-SP79; 30.9 DSP; 15 SSB; 40 SST |
SHIFTER - FRONT |
|
SHIFTER - REAR |
Shimano CUES U6000-10 |
INNER TUBE |
27.5x1.9/2.35 F.V |
TYRE - FRONT |
Maxxis Crossmark II; 27.5x2.25"; wire; reflecting line |
TYRE - REAR |
|
BOTTLE CAGE |
|
CARRIER |
MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
FENDER |
Sunnywheel SW-FA-311-65(MSB) |
KICKSTAND |
Atranvelo ED-100-PC |
LIGHT - FRONT |
Herrmans H-Black MR4 E |
LIGHT - REAR |
Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier |
FRAME LOCK |
Abus 4650 XL |
DRIVE UNIT |
Shimano EP6; 85Nm |
DRIVE COVER |
Drive Unit Cover for EP801/EP600 |
BATTERY |
Shimano EN806; 630Wh |
BATTERY CHARGER |
Shimano EC-E6002; 2A charging current |
BATTERY LOCK |
Abus Key |
DISPLAY |
Shimano SC-EN500 |
