01. FRAME | eONE-SIXTY LITE IV; MAT aluminium; 174 mm STR; 29x2.6" max. WHS; 148x12 AST; intube ; 750 Wh |
02. SIZES | Short - Mid - Long - XLong |
03. FORK | Marzocchi Z1 eMTB; Air; 170 STR; Tapered; 44mm fork offset; 29x2.6" max WHS |
04. REAR SHOCK | Marzocchi Bomber Air; platform |
05. DRIVE UNIT | Shimano EP801; 85Nm |
06. BATTERY | Trendpower Internal Battery Gen 2; 750Wh |
07. BATTERY CHARGER | Trendpower EU Charger; 4A |
08. DISPLAY | Shimano SC-EM800 |
09. MODE SWITCH | Shimano SW-EM800-L |
10. REAR DERAILLEUR | Shimano Deore RDM5130 LinkGlide 10 |
11. SHIFTERS | Shimano XT M5130 10 |
12. DROPPER POST LEVER | Shimano SL -MT500-L |
13. BRAKE - FRONT | Shimano Deore M6120; 4 piston |
14. BRAKE - REAR | Shimano Deore M6120; 4 piston |
15. ROTOR - FRONT | Shimano RT64; 220 mm |
16. ROTOR - REAR | Shimano RT-EM910; 203 mm |
17. CHAINRING | FSA 1x Steel Chainring; 36 ATC |
18. CRANK | Shimano FC-EM600; 165 mm for all sizes |
19. CHAIN | Shimano LG500 |
20. CASSETTE | Shimano LG400; 11-43 ATC; 10 GER |
21. PEDALS | VP VPE-527 |
22. HANDLEBAR | MERIDA EXPERT eTR; 780 WHB; 20 RHB |
23. HANDLEBAR STEM | MERIDA EXPERT eTR II; MAT aluminium; 35 DSH; 0 ASD; Supernova mount |
24. STEM LENGTH | 40 mm all sizes |
25. HEADSET | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
26. SEAT POST | MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XS: 125 SPT - S: 150 SPT - M/L: 200 SPT - XL: 230 SPT |
27. SADDLE | MERIDA EXPERT CC; V-mount |
28. HUB - FRONT | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
29. HUB - REAR | Shimano TC600-HM-B; 148x12 WHR; 32 SPH; Centerlock |
30. AXLE - REAR | MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
31. RIMS | MERIDA EXPERT TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 27.5" |
32. TYRE - FRONT | Maxxis Assegai; 29x2.5 "; fold; TR EXO+ 3C MaxxGrip |
33. TYRE - REAR | Maxxis DHR II; 27.5x2.6 "; fold; 3C EXO+ TR |
34. LIGHT FRONT | LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount |
35. LIGHT REAR | LEZYNE LED FEMTO USB REAR STVZO |
36. OTHER | MERIDA Multitool with saddlebox |
37. MAX RIDER WEIGHT | 140kg |
