| 01. FRAME | ONE-SIXTY LITE III; 171 STR mullet / 162 STR 29"; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| 02. SIZES | Short-Mid-Long-XLong |
| 03. FORK | DVO Onyx 38 D2; Air; 180 STR; tapered; 44mm Offset; 29" |
| 04. SHOCK | DVO Jade X D2; coil |
| 05. GEARS | 1 x 12 |
| 06. CRANKSET | Shimano MT512; 32 ATC |
| 07. CRANK LENGTH | 170 mm-S up |
| 08. BOTTOM BRACKET | Shimano BB-MT-501; 24mm |
| 09. CASSETTE | Shimano Deore M6100; 10-51 ATC; 12 GER |
| 10. CHAIN | KMC X12 |
| 11. REAR DERAILLEUR | Shimano Deore M6100 Shadow+; SGS |
| 12. SHIFTER - REAR | Shimano Deore M6100 |
| 13. DROPPER LEVER | Shimano SL-MT500-IL |
| 14. BRAKE - FRONT | TRP Trail Evo HD-M843; 4 piston |
| 15. BRAKE - REAR | TRP Trail Evo HD-M843; 4 piston |
| 16. ROTOR - FRONT | TRP RS01E; 220 mm |
| 17. ROTOR - REAR | TRP RC01E; 203mm |
| 18. HANDLEBAR | MERIDA EXPERT TR II; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB |
| 19. STEM | MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
| 20. STEM SIZE | 40 mm all sizes |
| 21. HEAD SET | Acros ICR MERIDA EXTERNAL neck; Upper and lower IPS sealing |
| 22. SEAT POST | MERIDA TEAM TR; 34.9 DSP; 0 SSB; all sizes 30-230 SPT |
| 23. SADDLE | MERIDA COMP SL; V-mount; incl. MERIDA minitool |
| 24. SPOKES | Double Butted Black stainless |
| 25. HUB - FRONT | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| 26. HUB - REAR | Shimano TC500-MS-B; 148x12 WHR; 32 SPH; Centerlock |
| 27. AXLE - REAR | MERIDA COMP TR; including removeable lever, 6mm allen key |
| 28. RIMS | MERIDA EXPERT TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 27.5" |
| 29. TYRE - FRONT | Continental Kryptotal-F; 29x2.4"; fold; TR; Enduro casing; Soft Compund |
| 30. TYRE - REAR | Continental Kryptotal-R; 27.5x2.4"; fold; TR; Downhill Casing; Soft Compound |
| 31. BOTTLE CAGE | - |
| 32. FENDER | - |
| 33. E-SHIFT PARTS | - |
| 34. OTHER | MERIDA Multitool with saddlebox |
| 35. OTHER | Velcro strap & Tube Base Mount LITE |
| 36. MAX RIDER WEIGHT | 135kg |
