| 01. FRAME | SCULTURA ENDURANCE LITE; MATaluminium; 700x35C max./ 700x32C (with fender) max. WHS; 100x12/ 142x12 AST; BB86 BBR |
| 02. SIZE | XS-S-M-L-XL |
| 03. FORK | SCULTURA ENDURANCE CF3 DISC; MAT carbon; 700x35C max. WHS |
| 04. GEARS | 2 x 10 |
| 05. CHAINWHEEL | Shimano Tiagra; 50-34 ATC |
| 06. CRANK/SIZE | 165mm-XXS, 170 mm-XS/S, 172.5 mm-M, 175 mm-L/XL |
| 07. BOTTOM BRACKET | SM-BB71-41B, Pressfit 86.5 |
| 08. CASSETTE | Shimano CS-HG500; 12-28 ATC; 10 GER |
| 09. CHAIN | KMC X10 |
| 10. DERAILLEUR - FRONT | Shimano Tiagra |
| 11. DERAILLEUR - REAR | Shimano Tiagra; GS |
| 12. SHIFTERS | Shimano Tiaga disc |
| 13. BRAKES | Shimano Tiagra; Hydraulic disc |
| 14. ROTOR - FRONT | Shimano RT10; 160mm |
| 15. ROTORS - REAR | Shimano RT10; 160mm |
| 16. HANDLEBAR | MERIDA EXPERT SLII; MAT aluminium; 380mm(XXS) , 400mm (XS-S) , 420mm (M-L) , 440mm (XL) |
| 17. STEM | MERIDA EXPERT CW; 31.8 DSH; MAT aluminium; -8 ASD |
| 18. STEM/SIZE | 80 mm-XXS, 90 mm-XS, 100 mm-S/M, 110 mm-L, 120 mm-XL |
| 19. HEAD SET | MERIDA-8158 Semi integrated HS |
| 20. SEAT POST | MERIDA COMP CC; MAT aluminium; 27.2 DSP; 5 SSB |
| 21. SADDLE | MERIDA COMP SL; V-mount |
| 22. HUB - FRONT | JY D981SB; 100x12 WHF; 28 SPH; Centerlock |
| 23. HUB - REAR | JY D872SB; 12-142 WHR; 28 SPH; Centerlock |
| 24. AXLE - FRONT | MERIDA COMP SL |
| 25. AXLE - REAR | MERIDA COMP SL; including removable lever; 6/4mm allen key |
| 26. SPOKES | Black stainless |
| 27. RIMS | MERIDA EXPERT SLII; 23 IWR; 25 HRI; MAT aluminium; Tubeless ready (tubeless tape and valves not included) |
| 28. TYRES | Maxxis Detonator; 700x32C; fold |
| 29. BOTTLE CAGE | - |
| 30. E-SHIFT PARTS | - |
| 31. E-SHIFT PARTS | - |
| 32. OTHER | - |
| 33. OTHER | - |
| 34. MAX RIDER WEIGHT | 120kg |
