2024 BIG SEVEN 20 (3x)

$899.00
$764.00 (Inc GST) (15% off)
CONTACT STORE
Code: MEBI24D100092
Select colour
Select Size


Share this page
01. FRAME BIG.SEVEN TFS III; MAT aluminium; 27.5 WHS; 135x9 AST; BSA BBR
02. SIZES XS-S
03. FORK Suntour XCT30 HLO; Coil; 100 STR; Lockout; 27.5x2.25" max. WHS
04. GEARS -
05. CHAINWHEEL Shimano TY301; 42-34-24 ATC
06. CRANK LENGTH 170 mm-XS/S, 175 mm-M/L
07. BOTTOM BRACKET Shimano BB-UN101 73-123
08. CASSETTE Sunrace CSM558AU; 11-32 teeth; 8 speed; Nickel
09. CHAIN KMC Z8.1
10. DERAILLEUR - FRONT Shimano FD-TY600
11. DERAILLEUR - REAR Shimano RD-M3020-8; SGS
12. SHIFTER - FRONT Microshift TS39 [or Shimano ST-EF505]
13. SHIFTER - REAR Microshift TS39 [or Shimano ST-EF505]
14. DROPPER LEVER -
15. BRAKES Tektro M275 [or Shimano BR-MT200]
16. ROTOR - FRONT Shimano RT10; 160 mm
17. ROTOR - REAR Shimano RT10; 160 mm
18. HANDLEBARS MERIDA CC; MAT aluminium; 690 WHB; 15 RHB
19. STEM MERIDA CC; MAT aluminium; 31.8 DSH; 6 ASD
20. STEM LENGTH 70 mm-XS/S, 80 mm-M, 90 mm-L
21. HEAD SET MERIDA M2345
22. SEAT POST MERIDA CC; MAT aluminium; 30.9 DSP; 15 SSB
23. SADDLE MERIDA Sport comfort
24. HUB - FRONT Shimano TX505; 100x9 WHF; 32 SPH; Centerlock
25. HUB - REAR Shimano TX505; 135x9 WHR; 32 SPH; Centerlock
26. AXLE - REAR Quick Release
27. SPOKES Black steel
28. RIMS MERIDA CC; 17 IWR; MAT aluminium
29. TYRES MERIDA K1080; 27.5x2.2"; wire
30. PEDALS VP VPE-891
31. OTHER -
32. MAX. RIDER WEIGHT 135kg
