| 01. FRAME | eSCULTURA LITE; MAT aluminium; 700x45C / 700x42C (with fender) / 27,5x47C max. WHS; 100x9/135x9 AST; BSA BBR |
| 02. SIZES | XS-S-M-L-XL |
| 03. FORK | MDF09; MAT carbon |
| 04. DRIVE UNIT | MAHLE X35+ Hub Engine; 40Nm |
| 05. BATTERY | MAHLE B1-D; 250Wh |
| 06. BATTERY CHARGER | MAHLE CHARGER-C; 2A charging current |
| 07. DISPLAY | - |
| 08. REAR DERAILLEUR | Shimano 105; GS |
| 09. SHIFTERS | - |
| 10. BRAKES | Shimano 105; 2 piston |
| 11. ROTOR - FRONT | Shimano RT64; 160 mm |
| 12. ROTOR - REAR | Shimano RT66; 160 mm |
| 13. CHAINWHEEL | Shimano 105; 50-34 ATC |
| 14. CRANK SIZE | 170 mm-XS/S/SM/ML, 175 mm-L/XL |
| 15. CHAIN | KMC e11s |
| 16. CASSETTE | Shimano 105; 11-32 ATC; 11 GER |
| 17. PEDAL | VP VPE-891 |
| 18. HANDLEBAR | MERIDA Expert CW; MAT aluminium; 400mm (XS/S), 420mm (M/L), 440 (XL) |
| 19. HANDLEBAR STEM | MERIDA EXPERT IR; MAT aluminium; 31.8 DSH; 5 ASD |
| 20. STEM SIZE | 80 mm- XXS/XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL |
| 21. SEAT POST | MERIDA EXPERT CC; MAT carbon; 30.9 DSP; 0 SSB |
| 22. SADDLE | MERIDA COMP SL; V-mount |
| 23. HUB - FRONT | VP CLK170F; 100x12 WHF; 28 SPH; Centerlock |
| 24. HUB - REAR | MAHLE X35+ Hub |
| 25. AXLE - REAR | - |
| 26. RIMS | MERIDA Expert SL; 17 IWR; 22 HRI aluminium; Tubeless ready (tubeless tape and valves not included) |
| 27. TYRES | Maxxis Pursuer; 700x32C; fold |
| 28. CARRIER | - |
| 29. FENDER | - |
| 30. KICKSTAND | - |
| 31. LIGHT - FRONTRONTRONT | CG-119PG-BLACK(1) |
| 32. LIGHT - REAREAREAR | CG-404RG-BLK |
| 33. FRAME LOCK | - |
| 34. MAX RIDER WEIGHT | 120kg |
