| 01. FRAME | SCULTURA ENDURANCE LITE; MATaluminium; 700x35C max./ 700x32C (with fender) max. WHS; 100x12/ 142x12 AST; BB86 BBR |
| 02. SIZES | XXS-XS-S-M-L-XL |
| 03. FORK | SCULTURA ENDURANCE CF3 DISC; MAT carbon; 700x35C max. WHS |
| 04. GEARS | 2 x 11 |
| 05. CHAINWHEEL | Shimano 105; 50-34 ATC |
| 06. CRANK/SIZE | 165mm-XXS, 170 mm-XS/S, 172.5 mm-M, 175 mm-L/XL |
| 07. BOTTOM BRACKET | SM-BB71-41B, Pressfit 86.5 |
| 08. CASSETTE | Shimano CS-HG700; 11-34 ATC; 11 GER |
| 09. CHAIN | KMC X11 |
| 10. DERAILLEUR - FRONT | Shimano 105 |
| 11. DERAILLEUR - REAR | Shimano 105; GS |
| 12. SHIFTERS | Shimano 105 disc |
| 13. BRAKES | Shimano 105; Hydraulic disc |
| 14. ROTORS | Shimano RT10; 160mm |
| 15. HANDLEBAR | MERIDA EXPERT SL; MAT aluminium; 380mm(XXS) ; 400mm (XS-S) ; 420mm (M); 440 (L-XL) |
| 16. STEM | MERIDA EXPERT CW; 31.8 DSH; MAT aluminium; -8 ASD |
| 17. STEM/SIZE | 80 mm-XXS, 90 mm-XS, 100 mm-S/M, 110 mm-L, 120 mm-XL |
| 18. HEAD SET | MERIDA-8158 Semi integrated HS |
| 19. SEAT POST | MERIDA EXPERT CC; 27.2 DSP; 15 SSB; Carbon |
| 20. SADDLE | MERIDA COMP SL; V-mount |
| 21. HUB - FRONT | VP CLK170F; 100x12 WHF; 28 SPH, Centerlock |
| 22. HUB - REAR | VP CLK270R; 142x12 WHR; 28 SPH; Centerlock |
| 23. AXLE - FRONT | MERIDA EXPERT SL |
| 24. AXLE - REAR | MERIDA EXPERT SL; including removable lever; 6/4mm allen key |
| 25. SPOKES | Double Butted Black stainless |
| 26. RIMS | MERIDA EXPERT SL; 17 IWR; 22 HRI; MAT aluminium; Tubeless ready (tubeless tape and valves not included) |
| 27. TYRES | Maxxis Detonator; 700x32C; fold |
| 28. E-SHIFT PARTS | - |
| 29. E-SHIFT PARTS | - |
| 30. OTHER | - |
| 31. MAX RIDER WEIGHT | 120kg |
