01. Frame
SILEX LITE; MAT aluminium; 700x38C / 650Bx45C max.WHS; 100x12/142x12 AST; BB86 BBR
03. Fork
MERIDA SILEX CF2; Tapered; MAT carbon; 700x38C / 650Bx45C max. WHS
05. Chainwheel
Shimano GRX600; 46-30 ATC
06. Crank/Size
170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL
07. Bottom Bracket
SM-BB71-41B, Pressfit 86.5
08. Cassette
Shimano CS-HG50; 11-36 ATC; 10 GER
10. Derailleur - Front
Shimano GRX400
11. Derailleur - Rear
Shimano GRX400
12. Shifters
Shimano GRX400 disc
13. Brakes
Shimano GRX400; Hydraulic disc
14. Rotors
Shimano RT10; 160mm
15. Handlebar
MERIDA EXPERT GR; MAT aluminium; 400mm (XS-S), 420mm (M), 440mm (L/XL)
16. Stem
MERIDA EXPERT CW; MAT aluminium; 31.8 DSH; -8 ASD
17. Stem/size
80 mm all sizes
18. Head Set
MERIDA M2331 Neck
19. Seat Post
MERIDA COMP CC; MAT aluminium; 30.9 DSP; 0 SSB
20. Saddle
MERIDA COMP SL; V-mount
21. Hub - Front
VP CLK170F; 100x12 WHF; 32 SPH; centerlock
22. Hub - Rear
VP CLK270R; 142x12 WHR; 32 SPH; centerlock
23. Axle - Front
MERIDA EXPERT SL
24. Axle - Rear
MERIDA EXPERT SL; including removable lever; 6/4mm allen key
25. Spokes
Black stainless
26. Rims
MERIDA COMP SL; 17 IWR; 22 HRI; MAT aluminium
27. Tyres
Maxxis Rambler; 700x38C; fold; TR; EXO
31. Max Rider Weight
120kg
