| 01. FRAME | BIG.SEVEN TFS III; MAT aluminium; 27.5 WHS; 135x9 AST; BSA BBR |
| 02. SIZES | XS-S |
| 03. FORK | Suntour XCR LOR; Air; 100 STR; Lockout; 42mm fork offset |
| 04. GEARS | 2 x 9 |
| 05. CHAINWHEEL | Shimano MT101-2; 36-22 ATC |
| 06. CRANK LENGTH | 170 mm-S, 175 mm-M up |
| 07. BOTTOM BRACKET | FSA TH-7420ST Cartridge Bearing |
| 08. CASSETTE | Shimano HG200; 11-36 ATC; 9 GER |
| 09. CHAIN | KMC M99 |
| 10. CHAINGUARD | n/a |
| 11. DERAILLEUR - FRONT | Shimano M2020-TS |
| 12. DERAILLEUR - REAR | Shimano Alivio Shadow |
| 13. SHIFTER - FRONT | Shimano Altus |
| 14. SHIFTER - REAR | Shimano Altus |
| 15. DROPPER LEVER | n/a |
| 16. BRAKES | Tektro M275; 2 piston |
| 17. ROTOR - FRONT | Shimano RT10; 180mm |
| 18. ROTOR - REAR | Shimano RT10; 160mm |
| 19. HANDLEBARS | MERIDA EXPERT CC; MAT aluminium; 720 WHB; 10 RHB |
| 20. STEM | MERIDA COMP CC; MAT aluminium; 31.8 DSH; 6 ASD |
| 21. STEM LENGTH | 50 mm all sizes |
| 22. HEAD SET | MERIDA M2346 Neck |
| 23. SEAT POST | MERIDA COMP CC; MAT aluminium; 30.9 DSP; 0 SSB |
| 24. SADDLE | MERIDA COMP SL; V-mount |
| 25. HUB - FRONT | Shimano TX505; 100x9 WHF; 32 SPH; Centerlock |
| 26. HUB - REAR | Shimano TX505; 135x9 WHR; 32 SPH; Centerlock |
| 27. AXLE - REAR | - |
| 28. SPOKES | Black stainless |
| 29. RIMS | MERIDA COMP CC; 20 IWR; MAT aluminium |
| 30. TYRES | Maxxis Ikon; 27.5x2.2"; wire |
| 31. PEDALS | VP VPE-891 |
| 32. OTHER | no |
| 33. MAX. RIDER WEIGHT | 135kg |
