01. frame
MATTS 7. SPEED; MAT aluminium; 27.5" WHS; 135x9 AST; BSA BBR
02. sizes
WXS-WSM-WMD-WLG
03. fork
Rock Shox Judy TK; Coil; 100mm suspension travel Lockout; 42mm fork offset
04. gears
2 x 9
05. chainwheel
Shimano MT101-2; 36-22 teeth
06. crank length
170 mm-XS/S, 175 mm-M/L
07. bottom bracket
Shimano BB-UN100
08. cassette
Shimano CS-HG200; 11-32 teeth; 9 speed
09. chain
KMC M99
10. chainguard
-
11. derailleur - front
Shimano FD-M2020-TS [2s]
12. derailleur - rear
Shimano RD-M370
13. shifter - front
Shimano ST-EF505-2L
14. shifter - rear
Shimano ST-EF505
15. dropper lever
-
16. brakes
Power DS100 (2 piston, hydraulic disc brake)
17. rotor - front
Shimano RT10; 160 mm
18. rotor - rear
Shimano RT10; 160 mm
19. handlebars
MERIDA CC; MAT aluminium; 640mm width; 25mm rise
20. stem
MERIDA CC; MAT aluminium; 31.8mm diameter; 17 degree Angle
21. stem length
XS/S/M-80 mm, L-90 mm
22. head set
FSA NO.10P Neck15
23. seat post
MERIDA CC; MAT aluminium; 27.2 Diameter; 15 Setback
24. saddle
MERIDA Sport comfort
25. hub - front
Shimano TX505; 100x9 WHF; 32 Spokes; Centerlock
26. hub - rear
Shimano TX505; 135x9 WHR; 32 Spokes; Centerlock
27. axle - rear
-
28. spokes
Black steel
29. rims
MERIDA CC; 17 IWR; MAT aluminium
30. tyres
MERIDA K1080; 27.5x2.2"; wire
31. pedals
Plastic VPE-891
32. other
-
33. max. rider weight
135kg
