01. frame
BIG.SEVEN SPEED; MAT aluminium; 27.5"
02. sizes
WXS-WSM-WMD-WLG
03. fork
Suntour XCE28; Coil; 100 STR
04. gears
3 X 7
05. crankset
Shimano TY301; 42-34-24 ATC
06. crank length
170 mm-XS,S,M. 175 mm-L
07. bottom bracket
Cartridge Bearing
08. cassette
Shimano CS-HG200-12-32, 7s
09. chain
CN-7s
10. chainguard
-
11. front derailleur
Shimano TY300, TOURNEY
12. rear derailleur
Shimano TY300, TOURNEY
13. shifter-front
Shimano ST-EF500
14. shifter-rear
Shimano ST-EF500
15. brakes
Jak-7 Mechanical Disc
16. rotor-front
Jak-7 160mm
17. rotor-rear
Jak-7 160mm
18. handlebar
MERIDA Comp; MAT aluminium; 620 Wide; 25 Rise
19. stem
MERIDA Comp; 31.8 Diameter
20. stem length
XS/S/M-80 mm, L-90 mm
21. head set
A-Head OS
22. seat post
MERIDA Speed; MAT aluminium; 27.2 Diameter
23. saddle
Merida Comfort L DDK-258
24. hub-front
Alloy Disc, Quick Release
25. hub-rear
Alloy Disc, Quick Release
26. axle-rear
-
27. spokes
Black steel
28. rims
MERIDA double D, alloy
29. tyres
INNOVA IA-2569 (27.5x2.1")
30. pedals
Plastic VPE-891
