| 01. FRAME | SuperFoxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 160mm travel, Forward Geometry, one piece Monoblock upper link, SuperBoost 12x157mm rear axle, tapered head tube, 73mm |
| 01A. FRAME | Dedicated 1x drivetrain design, telescopic seatpost internal routing, Max. capacity sealed bearings, ISCG 05 |
| 02. FORK | Ohlins RXF 38 M.2 29, 170mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, |
| 03. REAR SHOCK | Ohlins TTX Air 205X65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings |
| 04. SHOCK SETTINGS | C20 compression, R35 rebound. Volume reducers 16.000 (2xF+1E) |
| 05. HEADSET | Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreex45 degree, bottom 51.9x40x8x45 degreex45 degree |
| 06. STEM | Onoff Sulfur FG 30mm 0 degree, 6061 forged alloy, 31.8mm barbore |
| 07. HANDLEBAR | Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degree backsweep, 5 degree upsweep, 31.8mm barbore |
| 08. GRIPS | Onoff Twin, 1lock-on, 135mm |
| 09. SEATPOST | Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm |
| 10. SADDLE | SDG BEL-AIR 3.0, LPU foam, steel rails |
| 11. FRONT BRAKE | Sram DB8, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads |
| 12. REAR BRAKE | Sram DB8, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads |
| 13. BRAKE LEVER | Sram DB8, tool-free reach adjust |
| 14. FRONT HUB | e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts |
| 15. REAR HUB | e*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, Shimano freehub |
| 16. FRONT TIRE | Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead |
| 17. REAR TIRE | Maxxis Dissector 29x2.4WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead |
| 18. CRANKSET | Truvativ Descendant 7K Eagle, SuperBoost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm |
| 19. RINGS | 32T, CNC-machined alloy, X-SYNC 2 |
| 20. BOTTOM BRACKET | Sram DUB BSA, sealed bearings, 73mm |
| 21. PEDALS | N/A |
| 22. CHAIN | Sram SX Eagle, 12s, Powerlock |
| 23. REAR DERAILLEUR | Sram NX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1 |
| 24. CASSETTE | Sram XG-1230, 11-50T, 12s |
| 25. DERAILLEUR HANGER | Mondraker M068 |
| 26. SIZES | S: 380mm / M: 420mm / L: 470mm / XL: 510mm |
