| FRAME | C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal C |
| FORK | Fox 38 Float Factory GRIPX2, Tapered, 15x110mm, E-Bike Optimized, 170mm, Kashima Coated |
| SHOCK | Fox Float X2 Factory, 230x65mm, High/Low Speed Rebound & Compression w/ 2-Position Lever, Kashima Coated |
| DERAILLEUR FRONT | |
| DERAILLEUR REAR | Sram X0 Eagle AXS™ Transmission, 12-Speed |
| SHIFTERS | Sram AXS™ Pod Controller |
| BRAKES | Shimano XT BR-M8120, Hydr. Disc Brake (203/203) |
| CRANKSET | ACID MTB Hybrid Pro, 36T |
| BOTTOM BRACKET | |
| CHAIN | Sram GX Eagle™ Transmission |
| PEDALS | |
| CASSETTE (TEXT) | Sram XS-1275, 10-52T |
| HANDLEBAR | Race Face ERA 35 |
| HANDLEBAR STEM | CUBE Performance Stem E-MTB 35, FPI-Link |
| HEADSET | ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
| GRIP | ACID Disrupt, Soft Compound |
| SEAT POST | Fox Transfer Factory 31.6mm, Kashima Coated |
| SADDLE | ACID Venec EMTB Trail 140 |
| HUBS | |
| RIM | Newmen Beskar 30 base/strong, 28/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
| TYRES | F: Schwalbe Magic Mary, Addix Soft, Super Trail, Kevlar, 2.4 | R: Schwalbe Tacky Chan, Addix Soft, Super Gravity, Kevlar, 2.4 |
| LIGHT(S) | |
| ACCESSORIES | |
| MOTOR/DRIVE UNIT | Bosch Drive Unit Performance Line CX, Smart System |
| MOTOR POWER (WATTS) | |
| MOTOR TORQUE (NM) | |
| BATTERY | Bosch PowerTube |
| BRAKE TYPE | Hydraulic Disc Brake |
| WEIGHT | 24.1 kg |
| WEIGHT LIMIT |
