| FRAME | C:62 Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH, Full Integrated Battery, Advanced Internal Cab |
| FORK | Fox 38 Float Rhythm, 2-Position Sweep-Adjust GRIP Damper, Tapered, 15x110mm, E-Bike Optimized, 170mm |
| SHOCK | Fox Float X Performance, 230x65mm, Adjustable LSR w/ 2-Pos. Lever |
| DERAILLEUR FRONT | |
| DERAILLEUR REAR | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| SHIFTERS | Shimano XT SL-M8100-IR, Direct Attach |
| BRAKES | Shimano XT BR-M8120, Hydr. Disc Brake (203/203) |
| CRANKSET | ACID MTB Hybrid Pro, 36T |
| BOTTOM BRACKET | |
| CHAIN | KMC e12 |
| PEDALS | |
| CASSETTE (TEXT) | Shimano Deore CS-M6100, 10-51T |
| HANDLEBAR | CUBE Rise Trail Bar 35 |
| HANDLEBAR STEM | CUBE Performance Stem E-MTB 35, FPI-Link |
| HEADSET | ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
| GRIP | ACID Disrupt, Soft Compound |
| SEAT POST | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| SADDLE | ACID Venec EMTB Trail 140 |
| HUBS | |
| RIM | Newmen Performance 30, 28/32 Spokes (Base/Strong), 15x110mm / 12x148mm, Tubeless Ready |
| TYRES | F: Schwalbe Magic Mary, Addix Soft, Super Trail, Kevlar, 2.4 | R: Schwalbe Tacky Chan, Addix Soft, Super Gravity, Kevlar, 2.4 |
| LIGHT(S) | |
| ACCESSORIES | |
| MOTOR/DRIVE UNIT | Bosch Drive Unit Performance Line CX, Smart System |
| MOTOR POWER (WATTS) | |
| MOTOR TORQUE (NM) | |
| BATTERY | Bosch PowerTube |
| BRAKE TYPE | Hydraulic Disc Brake |
| WEIGHT | 24.7 kg |
| WEIGHT LIMIT | 125 kg |
