| 01. FRAME | Carbon XC Race |
| 02. FORK | RockShox SID Select, 120mm, 51mm Offset |
| 03. HEADSET | FSA Internal |
| 04. GRIPS | Ergon GA20 Lock-On |
| 05. HANDLE BAR | Butted Alloy Lite, 760mm, 15mm Rise |
| 06. STEM | Norco SL Alloy Stem, 60mm Length, 31.8mm Clamp |
| 07. SEAT POST | X-Fusion Manic Dropper, 31.6mm, 125mm (S), 150mm (M, L, XL) |
| 08. SADDLE | Fizik Alpaca Terra, Wingflex |
| 09. FRONT BRAKE | Shimano Deore BR-MT420, Matallic Pads, 4 Piston |
| 10. FRONT BRAKE ROTOR | Shimano SM-RT64, 180mm |
| 11. REAR BRAKE | Shimano Deore BR-MT420, Matallic Pads, 4 Piston |
| 12. REAR BRAKE ROTOR | Shimano SM-RT64, 180mm |
| 13. BRAKE LEVERS | Shimano BR-MT420 |
| 14. SHIFTER REAR | Shimano SLX SL-M7100-IR I-Spec EV |
| 15. REAR DERAILLEUR | Shimano XT RD-M8100 |
| 16. CASSETTE | Shimano SLX, 10-51T, 12 Speed |
| 17. CHAIN | Shimano Deore |
| 18. CRANKSET | Shimano FC-MT6100, 32T, 170mm (S), 175mm (M, L, XL) |
| 19. BOTTOM BRACKET | Shimano BB-MT500 PF92 |
| 20. FRONT HUB | Shimano HB-MT400-B, 15x110mm Boost, Center Lock |
| 21. REAR HUB | Shimano FH-MT510-B, 12x148mm Boost, Micro Spline, Center Lock |
| 22. SPOKES/NIPPLES | Stainless Black |
| 23. RIMS | Stan's Arch S1 29" 32H |
| 24. FRONT TIRE | Schwalbe Nobby Nic Evo, 2.35", Super Terrain, TLE |
| 25. REAR TIRE | Schwalbe Nobby Nic Evo, 2.35", Super Terrain, TLE |
| 26. SEALANT | Stan's - 200ml |
| 27. VALVES | Stan's Universal 35mm Presta |
| 28. RIM TAPE | Stan's |
| 29. FEATURES 1 | Revolver Carbon XC frame with 100mm or 120mm fork options |
| 30. FEATURES 2 | Updated progressive XC geometry |
| 31. FEATURES 3 | Gravity Tune |
| 32. FEATURES 4 | 148mm Boost rear end |
| 33. FEATURES 5 | Tubeless ready with Stan's tape, valves and sealant |
| 34. CHANGES 1 | New RockShox SID Select 120mm Fork |
| 35. CHANGES 2 | Shimano SLX/XT 12 Speed Drivetrain |
| 36. CHANGES 3 | - |
| 37. CHANGES 4 | - |
| 38. CHANGES 5 | - |
