| 01. FRAME | Carbon Front Triangle, Aluminum Rear, 125mm Travel, Ride Aligned |
| 02. FORK | Fox Performance Elite FLOAT 36, GRIP2, 140mm Travel, 42mm Offset |
| 03. REAR SHOCK | Fox Performance Elite FLOAT DPX2, 190x45mm |
| 04. HEADSET | FSA Internal Sealed Bearing |
| 05. HEADSET SPACER | 1x10mm/2 x 5mm- Black |
| 06. GRIPS | DMR Deathgrip |
| 07. HANDLE BAR | TranzX Butted 6061 Alloy, 780mm, 20mm Rise |
| 08. STEM | Norco 6061 Alloy, 45mm Length, 35mm Clamp |
| 09. SEAT POST | X-Fusion Manic dropper, 31.6mm, 125mm (S), 150mm (M,L), 170mm (XL) |
| 10. SEAT POST CLAMP | Norco Alloy Nutted Clamp |
| 11. SADDLE | Fizik Alpaca Terra, Wingflex |
| 12. FRONT BRAKE | Shimano XT BR-M8020, 4 Piston, Metallic Pads |
| 13. FRONT BRAKE ROTOR | Shimano SM-RT70 Ice Tech, 203mm |
| 14. REAR BRAKE | Shimano XT BR-M8020, 4 Piston, Metallic Pads |
| 15. REAR BRAKE ROTOR | Shimano SM-RT70 Ice Tech, 180mm |
| 16. BRAKE LEVERS | Shimano XT BR-M8020 |
| 17. SHIFTER REAR | Shimano XT SL-M8100 I-Spec EV |
| 18. REAR DERAILLEUR | Shimano XT RD-M8100 |
| 19. CASSETTE | Shimano XT CS-M8100, 10-51T, 12 Speed |
| 20. CHAIN | Shimano XT CN-M8100 |
| 21. CRANKSET | Praxis Girder Carbon M30, 32T, 170mm |
| 22. BOTTOM BRACKET | Praxis M30 BB92 |
| 23. CHAIN TENSIONER | - |
| 24. FRONT HUB | Shimano XT HB-8110-B, 15x110mm Boost, Center Lock |
| 25. FRONT HUB SKEWER | Fox Bolt Thru Axle |
| 26. REAR HUB | Shimano XT FH-8110-B 12x148mm Boost, 32H, Micro Spline, Center Lock |
| 27. REAR HUB SKEWER | 148mm x 12mm TA |
| 28. SPOKES/NIPPLES | Sapim Sprint DB Stainless |
| 29. RIMS | Stan's Flow S1 29", 32H |
| 30. FRONT TIRE | Vittoria Mazza 2.4" Trail G2.0 |
| 31. REAR TIRE | Vittoria Martello 2.35" Trail G2.0 |
| 32. SEALANT | Stan's - 200ml |
| 33. VALVES | Stan's Universal 35mm Presta Valve Stem |
| 34. RIM TAPE | Stan's Rim Tape 55m x 30mm (Fits Flow rims) |
| 35. FEATURES 1 | Optic Carbon 29" 125mm FT/6061 Alloy RT |
| 36. FEATURES 2 | Ride Aligned Trail geometry based around 140mm short offset forks |
| 37. FEATURES 3 | Slack 65 Degree HA |
| 38. FEATURES 4 | Short seat tubes with long travel droppers |
| 39. FEATURES 5 | Ride Aligned Suspension setup |
| 40. CHANGES 1 | Updated Chainstay and Seatstay - Stiffer, 180mm post mount brake, added heel clearance. |
| 41. CHANGES 2 | Vittoria Mazza and Martello tires w/Graphene 2.0 Compound |
| 42. CHANGES 3 | Stan's Tubeless Ready - Rims pre-taped, valves and sealant provided |
