00. COLOUR | SILK FALL GREEN(SILVER-GREEN) |
01. FRAME | BIG.TRAIL TFS; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
02. SIZE | S-M-L-XL |
03. FORK | Fox 34 Float Performance; Air; 140 STR; Tapered; 44mm fork offset; 29x2.6" max. WHS |
04. GEARS | 1 x 12 |
05. CHAINWHEEL | Race Face Aeffect; 32 ATC |
06. CRANK LENGTH | 170 mm-S, 175 mm-M up |
07. BOTTOM BRACKET | Race Face BSA 68/73 – 24mm |
08. CASSETTE | Shimano Deore M6100; 10-51 ATC; 12 GER |
09. CHAIN | KMC X12 |
10. DERAILLEUR-REAR | Shimano XT; SGS |
11. SHIFTER | Shimano XT; Multi Release |
13. DROPPER LEVER | Shimano SL-MT500-IL |
14. BRAKES | TRP Trail Evo HD-M843; 4 piston |
15. ROTOR-FRONT | TRP RC01E; 203mm |
16. ROTOR-REAR | TRP RC01E; 180mm |
17. HANDLEBARS | MERIDA COMP TR; MAT aluminium; 780 WHB; 20 RHB |
18. STEM | MERIDA EXPERT TR; MAT aluminium; 35 DSH; 0 ASD |
19. STEM LENGTH | 50 mm all sizes |
20. HEAD SET | MERIDA M2331 |
21. SEAT POST | MERIDA COMP TR; 30.9 DSP; 0 SSB; S: 125 SPT - M/L: 150 SPT - XL/XXL 175 SPT |
22. SADDLE | MERIDA EXPERT SL; V-mount; incl. MERIDA minitool |
23. HUB-FRONT | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
24. HUB-REAR | Shimano TC600-MS-B; 148x12 WHR; 32 SPH; Centerlock |
25. AXLE-REAR | MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
26. SPOKES | Double Butted Black stainless |
27. RIMS | MERIDA EXPERT TR; 29 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included) |
28. TYRES | Maxxis Dissector; 29x2.4"; fold; TR EXO Dual |
29. PEDALS | - |
30. OTHER | MERIDA Multitool with saddlebox |
31. OTHER | Trail Mount & Velcro strap |
32. MAX RIDER WEIGHT | 135kg |
