| 01. FRAME | CROSSWAY DT; MAT aluminium; 700x42C max. WHS; 135x9 AST; BSA BBR |
| 02. SIZE | XS-S-S/M-M/L-L-XL |
| 03. FORK | Suntour NEX; Coil; 63 STR; 700x50C max. WHS |
| 04. GEARS | 3 X 7 |
| 05. CHAINWHEEL | Shimano TY301; 48-38-28 ATC |
| 06. CRANK LENGTH | 170 mm-XXS/SM, 175 mm-ML/XXL |
| 07. BOTTOM BRACKET | FSA TH-7420ST-W, Cartridge Bearing |
| 08. CASSETTE | Shimano MF-TZ500; 14-28 ATC; 7 Speed |
| 09. CHAIN | KMC Z8.3 |
| 10. DERAILLEUR - FRONT | Shimano FD-TY610 |
| 11. DERAILLEUR - REAR | Shimano RD-M310 |
| 12. SHIFTER L | Shimano ST-EF500 |
| 13. SHIFTER R | Shimano ST-EF500 |
| 14. BRAKES | Promax MTV-117A |
| 15. ROTORS | N/A |
| 16. HANDLEBARS | MERIDA CC; MAT steel; 620 Wide; 30 Rise |
| 17. STEM | MERIDA TK; MAT aluminium; 25.4 Diameter; adjustable |
| 18. STEM LENGTH | 100 mm all sizes |
| 19. HEAD SET | FSA TH888 |
| 20. SEAT POST | MERIDA TK; 27.2 Diameter; 13 Setback; 40 SST |
| 21. SADDLE | MERIDA Cross Sport |
| 22. HUB - FRONT | Joytech JY-751DSE; 100x9 WHF; 32 Spokes |
| 23. HUB - REAR | Joytech JY-752DSE; 135x9 WHR; 32 Spokes |
| 24. AXLE | Quick Release |
| 25. SPOKES | Steel UCP |
| 26. RIMS | MERIDA K1171; 700x40C; wire |
| 27. TYRES | MERIDA K1171; 700x40C; wire |
| 28. PEDALS | VP VPE-891 |
| 29. MAX RIDER WEIGHT | 120kg |
