01. FRAME | MATTS J. 26; MAT aluminium; 27.5x2.25" max. WHS; 135x9 AST; BSA BBR |
02. SIZE | XS (34cm) |
03. FORK | Suntour XCR32-ATB LOR; Air; 100 STR; Lockout; 44mm fork offset; 27.5x2.4" max. WHS |
04. GEARS | 1 x 10 |
05. CHAINWHEEL | Shimano CUES U4000; 30 |
06. CASSETTE | Shimano LG300; 11-48 ATC; 10 GER |
07. CHAIN | Sunrace CN11A |
08. DERAILLEUR - FRONT | - |
09. DERAILLEUR - REAR | Shimano CUES U6000; GS |
10. SHIFTERS | Shimano CUES U6000 |
11. BRAKE LEVERS | Shimano |
12. BRAKES - FRONT | Shimano BR-MT200 |
13. BRAKES - REAR | Shimano BR-MT200 |
14. ROTOR - FRONT | Shimano RT10; 160 mm |
15. ROTOR - REAR | Shimano RT10; 160 mm |
16. HANDLEBARS | MERIDA CC; MAT aluminium; 640 WHB; 15 RHB |
17. STEM | MERIDA CC; MAT aluminium; 31.8 DSH; 6 ASD; 60mm |
18. HEAD SET | MERIDA M2345 |
19. SEAT POST | MERIDA CC; MAT aluminium; 30.9 DSP; 15 SSB |
20. SEAT CLAMP | MERIDA COMP QR |
21. SADDLE | MERIDA EXPERT JR |
22. HUB - FRONT | Shimano TX505; 100x9mm width front hub; 32 spoke holes; centrelock |
23. HUB - REAR | Shimano TX505; 135x9mm width rear hub; 32 spoke holes; centrelock |
24. SPOKES | Stainless Black |
25. RIMS | MERIDA CC; 17mm inner width; MAT aluminium |
26. TYRES | MERIDA K1227; 26x2.2"; fold |
27. PEDALS | VP VPE-891 |
28. KICKSTAND | - |
29. MAX RIDER WEIGHT | 135kg |
