| 01. FRAME | BIG.TRAIL TFS; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| 02. SIZES | S-M-L-XL |
| 03. FORK | Suntour XCM32 DS; Coil; 120 STR; Lockout; 46mm fork offset; 29x2.4" max. WHS 15mm thru-axle 15*100 |
| 04. GEARS | 1 x 10 |
| 05. CHAINWHEEL | Shimano Deore M5100; 32 ATC |
| 06. CRANK LENGTH | 170 mm-S, 175 mm-M up |
| 07. BOTTOM BRACKET | - |
| 08. CASSETTE | Shimano Deore M4100; 11-46 ATC; 10 GER |
| 09. CHAIN | KMC X10 |
| 10. CHAINGUARD | - |
| 11. DERAILLEUR - FRONT | n/a |
| 12. DERAILLEUR - REAR | Shimano Deore M5120 Shadow+ |
| 13. SHIFTER - FRONT | n/a |
| 14. SHIFTER - REAR | Shimano Deore M4100 |
| 15. DROPPER LEVER | n/a |
| 16. BRAKES | Tektro M275; 2 piston |
| 17. ROTOR - FRONT | Shimano RT10; 180mm |
| 18. ROTOR - REAR | Shimano RT10; 180mm |
| 19. HANDLEBARS | MERIDA EXPERT CC; MAT aluminium; 740 WHB; 10 RHB |
| 20. STEM | MERIDA COMP CC; MAT aluminium; 31.8 DSH; 6 ASD |
| 21. STEM LENGTH | 50 mm all sizes |
| 22. HEAD SET | MERIDA M4455 |
| 23. SEAT POST | MERIDA COMP CC; MAT aluminium; 30.9 DSP; 0 SSB |
| 24. SADDLE | MERIDA COMP SL; V-mount |
| 25. HUB - FRONT | Shimano MT400-B; 100x15 WHF; 32 SPH; Centerlock |
| 26. HUB - REAR | Shimano MT400-B; 148x12 WHR; 32 SPH; Centerlock |
| 27. AXLE - REAR | MERIDA COMP TR; including removeable lever, 6 allen key |
| 28. SPOKES | Black stainless |
| 29. RIMS | MERIDA COMP TR; 29 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included) |
| 30. TYRES | Kenda Regolith; 29x2.4"; wire |
| 31. PEDALS | VP VPE-891 |
| 32. OTHER | no |
| 33. MAX RIDER WEIGHT | 135kg |
